3D Built-In Lithium Battery Red Laser Level
  • 3D Built-In Lithium Battery Red Laser Level3D Built-In Lithium Battery Red Laser Level
  • 3D Built-In Lithium Battery Red Laser Level3D Built-In Lithium Battery Red Laser Level
  • 3D Built-In Lithium Battery Red Laser Level3D Built-In Lithium Battery Red Laser Level

3D Built-In Lithium Battery Red Laser Level

Model:NK360-S
Laizap Opto-electros is a professional China 3D built-in lithium battery red laser level manufacturer and supplier.Our products have won the trust and praise of many industry users for their excellent performance, stability, and high cost-effectiveness.

As a manufacturer of laser level gauges, Laizap Opto-electros constantly innovates in product research and development, committed to providing users with more intelligent and efficient measurement tools. The 3D built-in lithium battery red laser level is different from traditional laser levels. This device has a high-performance lithium battery built-in, which can provide longer continuous operation. Users do not need to take out the battery to charge it, significantly improving work efficiency and user convenience. Adopting advanced 3D laser technology, it can emit 360 degree red laser lines in all directions, adapting to more complex measurement needs and helping users easily achieve precise positioning from multiple angles. Whether in large-scale construction sites or small space decoration projects, this instrument can provide excellent measurement accuracy and great work flexibility, becoming a reliable assistant for professionals.

Laizap Opto-electros is a manufacturer specializing in the research and production of laser measurement technology, committed to providing high-precision laser measurement tools for industries such as construction, decoration, and engineering. Since its establishment, with years of technological accumulation and constantly innovative research and development concepts, it has gradually established a strong market competitiveness. With a profound understanding of laser technology and advanced manufacturing processes, the company has launched a series of laser measuring instruments, including a 3D built-in lithium battery red laser level, which are widely used in construction measurement, precise positioning, and engineering layout.

Technical Specification

Model NK360S
3D Cross Red Line Laser Level3D Cross Red Line Laser Level
Light Source-Red 630nm - 650nm
LD power 30mW
Accuracy ± 3mm / 10m
Laser class Level 2 (output power<1mW) Class 2
Laser beam one 360° horizontal line + two 360° vertical lines
Self-leveling range 4° ± 1°
Working distance 100ft/30m, 200ft/60m with detector (green beam)
Operating time 8H/first gear; 16H/second gear.
Power source 3.7V-5200mah lithium battery ( inside battery)
USB charging Yes
Mount size 1/4"-20 mounting thread
IP rating IP54
Function Self-leveling mode, manual mode, and pulse mode.
Working temperature -10℃ ~ 50℃
Storage temperature -20 ~ 70℃
Packing - Carry bag Kit included:
1. NK360-S laser level
2. L bracket
3. target plate
4. Type-C Power cable
5. instruction book
6. bag
7. color box
Packing - Plastic case Kit included:
1. NK360-S laser level
2. multiple bracket
3. target plate
4. Green glasses
5. Type-C Power cable
6. Power Adaptor
7. instruction book
8. plastic case
9. color sleeve
Key Points Summary 3D Laser Level Self Leveling 3x360°,
3D Red Beam Cross Line Laser for Construction and Picture Hanging,
3 x 360 Green Beam Three-Plane Leveling and Alignment Laser Tool,
Rechargeable Batteries ,
Magnetic Liftable Stand Included,
red Laser,

Laizap Opto-electros' 3D built-in lithium battery red laser level not only has excellent laser emission function, but also has many practical additional features. The instrument adopts a high-strength and impact resistant shell design, which can withstand the harsh environment of construction sites, such as high temperature, humidity, dust and other factors, ensuring its stable operation under various conditions. The built-in lithium battery not only has a long service life, but also is easy to charge, meeting the needs of long-term, high-intensity work. Widely used in various fields such as building installation, wall decoration, furniture layout, etc., it provides accurate and reliable measurement tools for construction teams, greatly improving construction efficiency and project quality.
